CF15..M
Corode unit with magnetic drive pump CPMD-15. This combination is equipped with an on/off switch and an air release and drain valve.
Models
- - Filter housing in PP: 10'', 20''
- - Stainless steel 316 metal parts.
- - PP filter housing: maximum liquid temperature in the case or PP is 80ºC.
Filter media
CF15..M will be delivered with cartridge or filterpaper.
Optional:
- - Dry run protector
- - Hand priming pump
- - Transport wheels
- - Precoat tank PP: 10''xØ310 (18liter) or 20”xØ310 (36liter)
Technical Specs
Q max:
Q min:
Pump head:
Motor:
20.4m3/h
4m3/h
PP
1.1kW, 400V, 3.85/2.22Amp, 3Ph, 50Hz, IP55
Other voltage options and 60Hz available on request.
